Double rotor powder separator for sand and gravel removal
The twin-rotor powder concentrator is a highly efficient and energy-saving powder classification device, primarily used for powder separation processes in industries such as cement, mineral powder, chemicals, and metallurgy. This device utilizes a twin-rotor structure and, by adjusting the rotor speed and airflow distribution, achieves precise classification of particles of varying sizes, improving the fineness of the finished product and production efficiency.
Efficient Classification: Dual rotors work together to optimize the airflow field, improving powder selection accuracy and efficiency.
Energy Saving and Consumption Reduction: Advanced aerodynamic design reduces system resistance and energy consumption.
Flexible Adjustment: Rotor speed, air volume, and other parameters can be adjusted to meet the classification requirements of different materials.
Compact Structure: Modular design minimizes footprint and is easy to install and maintain.
Wear-Resistant and Durable: Key components are made of wear-resistant alloy or ceramic materials to extend service life.
Double rotor powder separator for sand and gravel removal description
The twin-rotor powder classifier is a highly efficient and energy-saving powder classification machine, primarily used for powder classification processes in the cement, mineral powder, chemical, and metallurgical industries. This equipment utilizes a dual-rotor structure, which precisely classifies particles of varying sizes by adjusting the rotor speed and airflow distribution, improving final product fineness and production efficiency.
Key Features:
Efficient Classification: The dual rotors work in tandem to optimize the airflow field, enhancing classification accuracy and efficiency.
Energy Saving and Consumption Reduction: Advanced aerodynamic design reduces system resistance and energy consumption.
Flexible Adjustment: Rotor speed, air volume, and other parameters can be adjusted to meet the classification requirements of different materials.
Compact Structure: The modular design minimizes footprint and is easy to install and maintain.
Durable and Wear-Resistant: Key components utilize wear-resistant alloys or ceramics for a longer service life.
Double rotor powder separator for sand and gravel removal Technical Specification
| Equipment specifications
| TZX-400 | TZX-500 | TZX-6O0 | TZX-70O | TZX-800 | TZX-900 | TZX-1000 | |
| Hourly output （th) | Cement | 12-16 | 18-22 | 20-26 | 28-35 | 45-54 | 64-76 | 85-105 |
| Raw material | 16-20 | 21-28 | 30-35 | 35-46 | 55-65 | 80-90 | 110-130 | |
|
80 um Fineness (80 umGeve nes due) | Cement | 2-6 | 2-6 | 2-6 | 2-6 | 2-6 | 2-6 | 2-6 |
| Raw material | 8-10 | 8-10 | 8-10 | 8-10 | 8-10 | 8-10 | 8-10 | |
| （r/min） Spinde speed | 190-380 | 19D-38D | 150-350 | 130-320 | 130-320 | 130-320 | 110-280 | |
| Spindle motor | Model Model | YCTL180-4A | YCTI 200-4B | YCTL225-4A | YCTI 225-4B | YOTL280-4A | YCTL315-4A | YCTL335-4A |
| （t/min） speed | 125-1260 | 125-1250 | 125-1250 | 132-1320 | 132-1320 | 132-1320 | 132-1320 | |
| 〔Kw〕 Power | 4 | 7.5 | 11 | 15 | 22 | 37 | 55 | |
| Circulating fan | Model | SCFN 8C | SCFN 8C | SCFN 10C | SCEN: 12.5C | SCFN 12.50 | SCFNo 16B | SCFNo 16D |
| （m3/h） Air volume | 21373 | 32427 | 39437 | 67650 | 75200 | 91200 | 168000 | |
| （Pa) Wind pressure | 2367 | 2302 | 2302 | 2355 | 2325 | 2479 | 2700 | |
| Motor | Y180-2 | Y200L2-2 | Y225M-4A | Y250M-4A | Y280S-4 | Y300L-6 | Y300K-6 | |
| Power[Kw] | 15-18.5 | 22-30 | 37 | 55 | 75 | 110 | 132 | |
Double rotor powder separator for sand and gravel removal applications
Cement industry (raw meal, clinker, and slag fine powder separation)
Mineral powder processing (limestone, quartz powder, coal powder, etc.)
Chemical industry (classification of ultrafine powders such as calcium carbonate and talc)
Metallurgical industry (metal powder separation)
