High-efficiency cement three-separation powder separator
The three-stage powder concentrator is a highly efficient, multi-stage powder classification device suitable for high-precision particle size control in industries such as cement, mineral powder, and chemicals. It utilizes three-stage separation technology for coarse, medium, and fine powders, combining centrifugal force, airflow shear force, and gravity settling to achieve a more refined classification effect, improving both finished product quality and system output.
Three-stage high-efficiency separation: Through optimized structural design, precise classification of coarse, medium, and fine powders is achieved simultaneously, minimizing over-grinding.
Energy-saving and environmentally friendly: A low-resistance, high-efficiency cyclone dust collection system reduces energy consumption and dust emissions.
Intelligent adjustment: Utilizing variable frequency control, rotor speed and air volume can be flexibly adjusted to meet different material requirements.
High wear resistance: Key components (such as guide vanes and rotors) utilize wear-resistant alloys or ceramic liners for extended service life.
Modular design: Easy maintenance, adaptable to existing production line upgrades.
High-efficiency cement three-separation powder separator description
High-Efficiency Cement Three-Separation Powder Classifier
The three-separation powder classifier is a highly efficient, multi-stage powder classification device suitable for high-precision particle size control in industries such as cement, mineral powder, and chemicals. It utilizes three-stage separation technology for coarse, medium, and fine powders, combining centrifugal force, air shear force, and gravity settling to achieve finer classification, improving product quality and system output.
Key Features:
Three-Stage High-Efficiency Separation: Optimized structural design enables simultaneous and precise classification of coarse, medium, and fine powders, minimizing over-grinding.
Energy-Saving and Environmentally Friendly: A low-resistance, high-efficiency cyclone dust collection system reduces energy consumption and dust emissions.
Intelligent Adjustment: Utilizing variable frequency control, the rotor speed and air volume can be flexibly adjusted to meet different material requirements.
High Wear Resistance: Key components (such as guide vanes and rotors) utilize wear-resistant alloy or ceramic liners for extended service life.
Modular Design: Easy maintenance and adaptable to existing production line upgrades. Applications:
Cement Industry: Classification of raw materials, clinker, and slag powders
Non-metallic Minerals: Ultrafine processing of limestone, quartz powder, heavy calcium carbonate, talc, etc.
Chemical Industry/Metallurgy: Sorting of fine powders (such as calcium carbonate and metal powders)
Environmentally Friendly Materials: Resource Utilization of Fly Ash and Desulfurized Gypsum
High-efficiency cement three-separation powder separator technical sheet
item
model SEPAX-250 SEPAX-350 SEPAX-500 SEPAX-750 SEPAX-1000 SEPAX-1250 SEPAX-1500 SEPAX-2000 SEPAX-2500
Spindle 电机型号
Motor model YCTL225-4B YCTL250-4A YCTL 250-4e YCTL280-4A Y200L-4 Y225M-4 Y225M-4 Y250M-4 Y280S-4
power 15 18.5 22 30 30 37 45 55 75
Speed (rpm) 150~400 150~350 150~320 140~320 130~280 130~260 120~240 110~200 110~180
FAN Fan Model 9-26 No10C 9-26 No12.5C 9-26No125d SCF-12 No14C SCF-12 No14B SCF-12No16B SCF-12 No168 SCF-12 No18C| SCF-12 No18B
Speed (rpm) Speed 1000 1080 1130 1100 1200 1050 1200 1050 1200
Total pressure 5920 4921 4869 5764 5384 5582 5862 6272 5865
(m3h) Ar volume 21465 30533 41021 46796 61280 76040 96631 120740 154910
Motor model Y225M-4 Y250M-4 Y280S-4 Y280M-4 Y315M1-4 Y315M2-4 Y315M2-4 Y355L1-4 Y355M2-4
Power(kw) 45 55 75 90 132 160 200 250 315
CAPACITY Product fineness (45u 0~3 0~3 0~3 0~3 0~3 0~3 0~3 0~3 0~3
(m3/h) Air handling 16000 22000 30000 45000 60000 75000 90000 120000 150000
(t/h)
Max processing capacity 50 90 120 150 210 260 330 400 500
(t/h)
Production capacity
10-18
15-28
20-40
30-50
40-70 50-85 75-110 95-130 110-160
Cement Industry: Classification of raw materials, clinker, and slag powders
Non-metallic Minerals: Ultra-fine processing of limestone, quartz powder, heavy calcium carbonate, talc, etc.
Chemical Industry/Metallurgy: Sorting of fine powders (such as calcium carbonate and metal powders)
Environmentally Friendly Materials: Resource Utilization of Fly Ash and Desulfurized Gypsum
